Product Details:
|
| Product Name: | 10MM 5W/M Flexible Led Cob Strip | Power: | 5W |
|---|---|---|---|
| Voltage: | DC24V/DC12V | CRI: | 90 |
| Lumens: | 110-120LM/W | Color Temperature: | RED/ BLUE/ GREEN/ YELLOW/ PURPLE/ WHITE |
| Warranty: | 3 Years | Life Span: | 50000 Hours |
| Certificate: | CE ROHS LM-80 | Working Temperature(℃): | -65 - 80 |
| Application: | KTV/Commercial Light/Shopping Mall Light/ Swimming Pool Light | Chip Brand: | Sanan Chip/ Bridgelux Chip |
| High Light: | 10mm cob led light strip,25W cob led light strip,10mm cob flexible led strip |
||
10MM 5W/M 25W/Roll CRI90 480/LEDs DC12V/24V Smart WiFi Brighter LED COB Strip Lights For Home, Ice Rink, TV, Party
Product Description
COB FOB STRIP: High Density, High CRI, High Brightness, Uniform Light Emission, No Graininess, No Light Spot, No Shadow, Customized Light Color according to Customers' Requirements, Achieve a Perfect Linear Light Source. IP20 for Indoor Use Only, IP67 for Outdoor Use Only, Multiple Functions, Used in Multiple Occasions
Specification
Product characteristic parameters
| Company abbreviation |
Product size (mm) |
(V) |
Half a meter powe (W) | Half-meter shear group numbe | emitting color | CRI |
Photosynthetic efficiency level (lm/w) |
Color tolerance |
| XC | 500*10mm | DC12V | 2.5W | 20 | 2700K | >90 | 100-105 | ≤3 |
| XC | 500*10mm | DC12V | 2.5W | 20 | 3000K | >90 | 110-115 | ≤3 |
| XC | 500*10mm | DC12V | 2.5W | 20 | 4000K | >90 | 120-125 | ≤3 |
| XC | 500*10mm | DC12V | 2.5W | 20 | 6500K | >90 | 120-125 | ≤3 |
Product size image
Reliability test standards
|
(Apilot project) |
(Number of test) |
(Test conditions) |
(Decision criteria) |
(Test Vequipment) |
| Cold and hot shock |
10pcs |
-40℃/30min -- 120℃/30min, one Cycle per hour, 100 cycles in total. |
No glue crack/dead light |
Cold and heat shock chamber |
| The normal temperature aging |
10pcs |
Ambient temperature 25±5℃, rated voltage /1000hr, 168H to test the photoelectric parameters once. |
1Droop 10% or less 2.No glue crack/dead light |
Normal temperature aging block |
| High temperature and high humidity |
10pcs |
Ambient temperature 85±5℃, rated voltage /1000hr, 168H to test the photoelectric parameters once. |
1.Droop 10% or less 2. No glue crack/dead light |
High temperature and high humidity aging tank |
Packing method
1. Reel packaging
| LED light barwidth | Reel size | Meters per roll | Number of rolls per carton |
| 4mm | 5.1 inches | 5 | 10 |
| 8mm | 5.1 inches | 5 | 10 |
| 10mm | 5.1 inches | 5 | 10 |
2. Blister box packaging
|
LED light barwidth |
Blister box size |
The packing layer |
Number of packing strips per carton |
| 4mm | 510*123*25mm | 10 | 300 |
| 8mm | 510*123*25mm | 10 | 150 |
| 10mm | 510*123*25mm | 10 | 120 |
Application to Anywhere You Want to Use
It can decorate your bedroom, ceiling, stairs, kitchen cabinet, porch, desk, and living room, especially great for holidays like Christmas, Halloween, Parties etc
Trade Show
Customers feedback
1. These are much better when used as under cabinet lighting than the standard chip style. Especially with reflective countertops. It's much more uniform and clean looking in the reflection. I install many strips through my electrical business. These were very great.
2. Great lights for background color. These lights work with Alexa so I have setup a group named background and I just have to instruct Alexa to set background to any desired color.
3. I love these light strips! I just got them in today. I immediately installed them on the back of my 55” Samsung flatscreen. Installation was easy. The 3M backing really stuck well, and time will tell how long they stay on. Hopefully a really long time!
Once installed, I turned the lights on, and paired with my home WiFi. You download The ap, create an account, and then pair your device. I also went to my Alexa ap and enables the Alexa skill for the Govee, and it works perfect. I tested out the music mode and several other modes, adjusted brightness up and down, and it works great.
4. These lights are excellent! Very well made and stick very well. The look behind my tv is freaking awesome! I cant tell you how much better my living room looks now! Definitely a great choice, will buy more!
5. I normally don't write reports but I was surprised for good about this product. Unbelieved brightness. Consider using a dimmer to control the bright. For sure I will buy a few more for my home project.
