CCT Tunable Dual Color DC24V 10W Flexible FOB led strip Light

I'm Online Chat Now

CCT Tunable Dual Color DC24V 10W Flexible FOB led strip Light

CCT Tunable Dual Color DC24V 10W Flexible FOB led strip Light
CCT Tunable Dual Color DC24V 10W Flexible FOB led strip Light CCT Tunable Dual Color DC24V 10W Flexible FOB led strip Light CCT Tunable Dual Color DC24V 10W Flexible FOB led strip Light CCT Tunable Dual Color DC24V 10W Flexible FOB led strip Light

Large Image :  CCT Tunable Dual Color DC24V 10W Flexible FOB led strip Light

Product Details:
Place of Origin: China
Brand Name: XUANCAI
Certification: CE ROHS LM-80
Model Number: FOB LED COB STRIP
Payment & Shipping Terms:
Minimum Order Quantity: 5 meter
Price: $ 5-$ 6/meter
Packaging Details: Blister box packaging
Delivery Time: 3-5 days
Payment Terms: T/T, Western Union, Paypal , Alibaba trade assurance
Supply Ability: 100000M / Month

CCT Tunable Dual Color DC24V 10W Flexible FOB led strip Light

Description
Product Name: Cob Flexible Led Strip Light Power: 10W+10W
Voltage: DC24V CRI: >90
Lumens: 110-120LM/W Color Temperature: 2700K+6500K
Warranty: 3 Years Life Span: 50000 Hours
Certificate: CE ROHS LM-80 Working Temperature(℃): -20 - 50
Application: Parting Cabinet Bedroom Kitchen Home Decor Light Color: Warm White+ Cool White
High Light:

100W led strip chip

,

16ft led strip chip

,

16ft led strip red

CCT Tunable Dual Cob Led Strip Lights CRI90 2700K+6500K 16.4Ft DC24V 100W Flexible DIY Strip Light



CCT Tunable DualTwo Color Temperature 2700K and 6500K ,CRI 90 , 576 LED /16.4 ft .Choose Different Color Temperatures Arbitrarily in Different Environments , You can Buy Dimming Controller to Match. Alternative the Color Connect Different Line . The LED Strip Lighting is Working at DC 24V .





Product parameters

Company abbreviation

Product size

(mm)

Input voltage

(V)

Half a meter powe (W) Half-meter shear group numbe emitting color CRI

Photosynthetic efficiency level

(lm/w)

Color tolerance
XC 500*12mm DC24V 10W 18 2700K >90 100-110 ≤3
XC 500*12mm DC24V 10W 18 6500K >90 110-120 ≤3







Specification

  • LEDs Type: FOB LED COB STRIP LIGHT
  • Input Voltage: DC24V
  • Wattage: 10W+10W
  • Total length: 3.3ft/1m
  • FPCB width: 12MM
  • View angle: 180°
  • LED quantity: 576LEDs
  • Lumen: 1450-1500lm
  • Color Rendering Index: >80
  • Waterproof level: IP20 Non-waterproof/ IP67-waterproof
  • Color temperature: Warm white 2700K+ Cool White 6500K
  • Operation temperature: -20℃-+45℃
  • Storage temperature: -20℃-+60℃







Product dimension

CCT Tunable Dual Color DC24V 10W Flexible FOB led strip Light 0





CCT Tunable Dual Color DC24V 10W Flexible FOB led strip Light 1







Reliability test standards

 (A pilot  project)



(Number of test)

(Test conditions)

(Decision criteria)

(Test Vequipment)

Cold and hot shock 10pcs -40℃/30min -- 120℃/30min, one Cycle per hour, 100 cycles in total. 1. No glue crack/dead light



Cold and heat shock chamber

The normal temperature aging 10pcs Ambient temperature 25±5℃, rated voltage /1000hr, 168H to test the photoelectric parameters once.

1.Droop 10% or less

2.No glue crack/dead light

Normal temperature aging block

High temperature and high humidity 10pcs Ambient temperature 85±5℃, rated voltage /1000hr, 168H to test the photoelectric parameters once.

1.Droop 10% or less

2.No glue crack/dead light



High temperature and high humidity aging tank





Product features

①  CCT LED Strip is Best Solution for LED Profile , If Install LED Strip Inside LED Profile without Dark Dot . Why We Do DC24V LED Strip Instead of DC12V , Use DC24V Driver to Match with LED Strip , It will Protect LED Strip for Longer Lifetime

②  Super Bright and Quality: The New COB Design Simply Uses the Chips Directly, Which Makes the Emitting Units Unprecedentedly Close to Each Other and Create Super Even Lighting Performance.Cob strip light that produces up to 3040 LEDS Diod by 16.4ft .Light NO glare,Soft light, No mercury, No UV, Safe to eye.

③  Easy to install: With strongest 3M adhesive backing and the 10mm width is easy to install in narrow places.It Can Be Cut Along the Cutting Position 26.31mm / 1.03 ft .Idea for Kitchen, Cabinet, Bedroom, Stair, Mirror, Corridor, DIY Backlight, Table Lamp, Toy Light, and other Places that Need Decoration.

④ Application: CCT LED Strip can be Used in Different Place .Such as : Architectural Decorative Lighting,Indoor Decoration , Stairway Lighting , Auditorium Walkway Lighting.





Application to Anywhere You Want to Use



CCT Tunable Dual Color DC24V 10W Flexible FOB led strip Light 2CCT Tunable Dual Color DC24V 10W Flexible FOB led strip Light 3





HOW TO INSTALL



CCT Tunable Dual Color DC24V 10W Flexible FOB led strip Light 4







Customers feedback

1.  These are much better when used as under cabinet lighting than the standard chip style. Especially with reflective countertops. It's much more uniform and clean looking in the reflection. I install many strips through my electrical business. These were very great.



2.  My customer is so happy with this lighting. The leds are bright and dimmable and a great white shade., not blue or amber. Most importantly they are a solid light, no dots. Looks very high end. This is the only led strip lighting I will install from now on.



3.  I have used a ton of other products from skye and this is by far my favorite. It looks awesome without all the individual diodes. I used a 24v transformer and made sure the wattage was rated higher that the 3w per ft I planned to use. These bend much tighter and are more flexible than other brands if used as well. I combine these with aluminum channels I buy from amazon to make them look like a fixture, including inside and outside corners.
Awesome light



4.  Great tape lighting...such an upgrade from the "dotted" style. Would HIGHLY recommend this product for under cabinet, under counter, around mirrors in bathrooms, etc.



5.  I normally don't write reports but I was surprised for good about this product. Unbelieved brightness. Consider using a dimmer to control the bright. For sure I will buy a few more for my home project.
