Product Details:
|
Model: | 8MM 15W/M Flexible Led Cob Strip Light | Wattas: | 10W |
---|---|---|---|
Voltage: | DC12V/ DC24V | CRI: | >90 |
Luminous Efficacy: | 110-120LM/W | CCT: | 2700K/ 3000K/ 4000K/ 6500K |
LED Qty(LEDs/M): | 512LEDs | Chip Brand: | Sanan Chip |
Packaging Details: | 5Meter/Roll | Storage Temperature: | -40...+85 |
Working Temperature: | -20...+45 | Certification: | CE ROHS LM-80 |
Warranty: | 2-3 Years Warranty | Spanlife: | 50,000Hours |
IP Rating: | IP20/ IP67 | PCB Width: | 8MM |
High Light: | Dimmable COB LED Strip,led strip remote control,2mm led strip |
High CRI90 White LED Strip Lights Flexible COB Tape Light Dimmable Lights with RF Remote For Home/ Cabinet light
What is the COB LED Strip Lights
Product Description
Product size (mm) |
Input voltage (V) |
Half a meter powe (W) | Emitting color | CRI | Luminous efficiency (LM/W) |
Color tolerance |
500*8mm | DC24V | 7.5W | 2700K | >90 | 95-100 | ≤3 |
500*8mm | DC24V | 7.5W | 3000K | >90 | 100-105 | ≤3 |
500*8mm | DC24V | 7.5W | 4000K | >90 | 110-115 | ≤3 |
500*8mm | DC24V | 7.5W | 6500K | >90 | 115-120 | ≤3 |
Reliability test standards
(Apilot project) |
(Number of test) |
(Test conditions) |
(Decision criteria) |
(Test Vequipment) |
Cold and hot shock |
10pcs |
-40℃/30min -- 120℃/30min, one Cycle per hour, 100 cycles in total. |
No glue crack/dead light |
Cold and heat shock chamber |
The normal temperature aging |
10pcs |
Ambient temperature 25±5℃, rated voltage /1000hr, 168H to test the photoelectric parameters once. |
1Droop 10% or less 2.No glue crack/dead light |
Normal temperature aging block |
High temperature and high humidity |
10pcs |
Ambient temperature 85±5℃, rated voltage /1000hr, 168H to test the photoelectric parameters once. |
1.Droop 10% or less 2. No glue crack/dead light |
High temperature and high humidity aging tank |
Packing method
1. Reel packaging
LED light barwidth | Reel size | Meters per roll | Number of rolls per carton |
4mm | 5.1 inches | 5 | 10 |
8mm | 5.1 inches | 5 | 10 |
10mm | 5.1 inches | 5 | 10 |
2. Blister box packaging
LED light barwidth |
Blister box size |
The packing layer |
Number of packing strips per carton |
4mm | 510*123*25mm | 10 | 300 |
8mm | 510*123*25mm | 10 | 150 |
10mm | 510*123*25mm | 10 | 120 |
Application
①Outdoor Lighting: Buildings, Advertising walls, Signs, Christmas decorations, Swimming pool, Park, Ice rinks
②Indoor Lighting: Polygonal wall, Ceiling groove design of hotel, Nightclub , KTV etc
③Home dark groove edge : Door frame, Bar, Wine cabinet, Wardrobe, TV cabinet...)
④Car beauty, Cabinet lights, Staircase lights, Wardrobe lights, Mirror lights, Frame lights, Advertising light boxes, Balance bikes
Customer feedback
1. I put a video up of what it looks like in a completely dark room. The remote is super easy to use and there's a control of how bright you want it. There's a flasher mode that is strobe to the max! We were going to put in the garage, but I liked it so much I use it in my at home work space. I'm waiting on some new office stuff before I stick it, so I've been draping it around. Everyone wants one now in their room because it brightens it up so well.
2. I have used smd led strips for over a decade now. I have seen them all some are better than other for sure, but hands down these are the brightest I have ever used. Their uniform light and flicker free dimmability is well worth paying a little more for. I bought them to replace 5050 smd lights. I figured 2 rows of the COB should be able to replace my current set up of row rows. Turns out Just one row was more than enough. Great product !!! Let’s see how they hold up over time. Fingers crossed.
3. Four different brightness settings. My husband and I really like them. Great product! Easy to install and very bright. Perfect for my diy vanity station for applying makeup in the morning. Our bedroom does not get the best morning light so this helps a lot!
