Product Details:
|
| Width: | 4MM / 8MM / 10MM | Voltage: | 12v /24v |
|---|---|---|---|
| Watts: | 5w / 10w / 15w /M | Lumens: | 100-110lm |
| CRI: | 90 | Lifespan:: | 50000 Hours |
| Lamp Body Material: | Aluminium | Warranty: | 3 Years |
| Application: | Landscape, Residential Office Road Garden Theme Park | Color Temperature: | 2700k / 3000K / 4000k / 6000K |
| High Light: | flexible cob led strip,8MM cob led strip,8MM flexible led light strip |
||
Product Nomenclature
XC --10 ---12 --- 0460---P7---J20 ---27 ---90 ---B---B2
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩
① :Company abbreviation
② :product size
④ : series-parallel
⑤ : Half a meter power
⑥ : Half-meter shear group number
⑦ :CT(K)
⑧:CRI
⑨:Photosynthetic efficiency level
Product Characteristic Parameters
| Company abbreviation |
product size (mm) |
(V) |
series-parallel |
Half a meter powe (W) |
Half-meter shear group numbe |
emitting color |
CRI |
Photosynthetic efficiency level (lm/w) |
|
color tolerance |
| XC | 10 | 12 | 0460 | P7 | J20 | 27 | 90 | B | B2 | S3 |
| (xuancai) | 500*10mm | DC12V |
04-C 60-B |
7.5W | 20 | 2700K | ＞90 | 100-105 | (Blister box) | ≤3 |
| XC | 10 | 12 | 0460 | P7 | J20 | 30 | 90 | C | B2 | S3 |
| (xuancai) | 500*10mm | DC12V |
04-C 60-B |
7.5W | 20 | 3000K | ＞90 | 110-115 | (Blister box) | ≤3 |
| XC | 10 | 12 | 0460 | P7 | J20 | 40 | 90 | C | B2 | S3 |
| (xuancai) | 500*10mm | DC12V |
04-C 60-B |
7.5W | 20 | 4000K | ＞90 | 115-120 | (Blister box) | ≤3 |
| XC | 10 | 12 | 0460 | P7 | J20 | 65 | 90 | D | B2 | S3 |
| (xuancai) | 500*10mm | DC12V |
04-C 60-B |
7.5W | 20 | 6500K | ＞90 | 120-125 | (Blister box) | ≤3 |
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
A: Low MOQ, 1pc for sample checking is available
A: We usually ship by DHL. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
A: Yes, we offer 2-3years warranty to our products.
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution i
ncluding re-call according to real situation.
